6109EVEV5
Drive Devices
Jing-Jin TZ460XSE02
Battery level
138.24kWh（576V 240Ah）
6109EVEV7
Drive Devices
lvkon
Battery level
202.9kWh
6109EVEV9
Drive Devices
lvkon
Battery level
267kWh
6109EVEV10
Drive Devices
Auto Ekontrol
Battery level
303.6/267kWh
6109EVEV13
Drive Devices
lvkon TZ410XS-LKM2504
Battery level
255.4/281.9kWh
6109EVEV14
Drive Devices
lvkon TZ410XS-LKM2504
Battery level
303.4/315kWh
  • Specifications
    close
    Dimensions(length/width/height)(mm) 10490x2482x3100/3250
    Model of the driving motor Jing-Jin TZ460XSE02
    Power rating(kW/r/min) 135
    Maximum gross mass（kg） 17000
    Curb weight（kg） 10350/10700
    Bulletin seats（seat） 18-32
    Rated seats（person） 102/96
    Wheel base（mm) 6100
    Wheel track（mm） 2085/1860
    Approaching angle/departure angle(°) 8/11
    Suspension Air suspension
    Specification on tires 275/70R22.5
    Energy storage system LiFePO4 battery/CATL
    Battery level 138.24kWh（576V 240Ah）
    Optional configuration AC, electric defroster, interior electronic service devices
    Maximum speed(km/h) 69
  • Specifications
    close
    Dimensions(length/width/height)(mm) 10490x2482x3100/3250
    Model of the driving motor lvkon
    Maximum gross mass（kg） 17000
    Curb weight（kg） 10500/10900
    Bulletin seats（seat） 20-32
    Rated seats（person） 92/84
    Wheel base（mm) 6100
    Approaching angle/departure angle(°) 8/11
    Suspension Air suspension
    Specification on tires 275/70R22.5
    Optional configuration 空调、独立水暖、公交服务设施
    Maximum speed(km/h) 69
  • Specifications
    close
    Dimensions(length/width/height)(mm) 10490x2482x3100/3250
    Model of the driving motor lvkon
    Maximum gross mass（kg） 17000
    Curb weight（kg） 10500/10900
    Bulletin seats（seat） 92/84
    Rated seats（person） 92/84
    Wheel base（mm) 6100
    Approaching angle/departure angle(°) 8/11
    Suspension Air suspension
    Specification on tires 275/70R22.5
    Optional configuration 空调、独立水暖、公交服务设施
    Maximum speed(km/h) 69
  • Specifications
    close
    Dimensions(length/width/height)(mm) 10490x2482x3100/3250
    Model of the driving motor Auto Ekontrol
    Maximum gross mass（kg） 17000
    Curb weight（kg） 10500/10900
    Bulletin seats（seat） 92/84
    Rated seats（person） 92/84
    Wheel base（mm) 6100
    Approaching angle/departure angle(°) 8/11
    Suspension Air suspension
    Specification on tires 275/70R22.5
    Optional configuration 空调、独立水暖、公交服务设施
    Maximum speed(km/h) 69
  • Specifications
    close
    Dimensions(length/width/height)(mm) 10500x2500x3070/3110/3260/3300
    Model of the driving motor lvkon TZ410XS-LKM2504
    Maximum gross mass（kg） 18000
    Curb weight（kg） 10600/11000/11400
    Rated seats（person） 78/18-39或97/18-39
    Wheel base（mm) 5800
    Approaching angle/departure angle(°) 9/11
    Suspension 钢板弹簧，气簧
    Specification on tires 275/70R22.5
    Energy storage system LiFePO4 battery/CATL
    Optional configuration AC, electric defroster, interior electronic service devices
    Maximum speed(km/h) 69
  • Specifications
    close
    Dimensions(length/width/height)(mm) 10500x2500x3070/3130/3230/3290
    Model of the driving motor lvkon TZ410XS-LKM2504
    Maximum gross mass（kg） 18000
    Curb weight（kg） 10800/11200/11600
    Rated seats（person） 78/18-39或97/18-39
    Wheel base（mm) 5800
    Approaching angle/departure angle(°) 9/11
    Suspension 钢板弹簧，气簧
    Specification on tires 275/70R22.5
    Energy storage system LiFePO4 battery/CATL
    Optional configuration AC, electric defroster, interior electronic service devices
    Maximum speed(km/h) 69
