6109EVEV5
Drive Devices
Jing-Jin TZ460XSE02
Battery level
138.24kWh（576V 240Ah）
| Specifications | |
|---|---|
| Dimensions（length x width x height）(mm) | 10490x2482x3100/3250 |
| Model of the driving motor | Jing-Jin TZ460XSE02 |
| Power rating(kW/r/min) | 135 |
| Maximum gross mass（kg） | 17000 |
| Curb weight（kg） | 10350/10700 |
| Bulletin seats（seat） | 18-32 |
| Rated seats（person） | 102/96 |
| Wheel base（mm) | 6100 |
| Wheel track（mm） | 2085/1860 |
| Approach/departure angle(°) | 8/11 |
| Suspension system | Air suspension |
| Tire | 275/70R22.5 |
| Energy storage system | LiFePO4 battery/CATL |
| Battery level | 138.24kWh（576V 240Ah） |
| Optional configuration | AC, electric defroster, interior electronic service devices |
| Maximum speed（km/h） | 69 |
6109EVEV7
Drive Devices
Lvkon
Battery level
202.9kWh
| Specifications | |
|---|---|
| Dimensions（length x width x height）(mm) | 10490x2482x3100/3250 |
| Model of the driving motor | Lvkon |
| Maximum gross mass（kg） | 17000 |
| Curb weight（kg） | 10500/10900 |
| Bulletin seats（seat） | 20-32 |
| Rated seats（person） | 92/84 |
| Wheel base（mm) | 6100 |
| Approach/departure angle(°) | 8/11 |
| Suspension system | Air suspension |
| Tire | 275/70R22.5 |
| Optional configuration | AC, electric defroster, interior electronic service devices |
| Maximum speed（km/h） | 69 |
6109EVEV9
Drive Devices
Lvkon
Battery level
267kWh
| Specifications | |
|---|---|
| Dimensions（length x width x height）(mm) | 10490x2482x3100/3250 |
| Model of the driving motor | Lvkon |
| Maximum gross mass（kg） | 17000 |
| Curb weight（kg） | 10500/10900 |
| Bulletin seats（seat） | 92/84 |
| Rated seats（person） | 92/84 |
| Wheel base（mm) | 6100 |
| Approach/departure angle(°) | 8/11 |
| Suspension system | Air suspension |
| Tire | 275/70R22.5 |
| Optional configuration | AC, electric defroster, interior electronic service devices |
| Maximum speed（km/h） | 69 |
6109EVEV10
Drive Devices
Auto Ekontrol
Battery level
303.6/267kWh
| Specifications | |
|---|---|
| Dimensions（length x width x height）(mm) | 10490x2482x3100/3250 |
| Model of the driving motor | Auto Ekontrol |
| Maximum gross mass（kg） | 17000 |
| Curb weight（kg） | 10500/10900 |
| Bulletin seats（seat） | 92/84 |
| Rated seats（person） | 92/84 |
| Wheel base（mm) | 6100 |
| Approach/departure angle(°) | 8/11 |
| Suspension system | Air suspension |
| Tire | 275/70R22.5 |
| Optional configuration | AC, electric defroster, interior electronic service devices |
| Maximum speed（km/h） | 69 |
6109EVEV13
Drive Devices
LvkonTZ410XS-LKM2504
Battery level
255.4/281.9kWh
| Specifications | |
|---|---|
| Dimensions（length x width x height）(mm) | 10500x2500x3070/3110/3260/3300 |
| Model of the driving motor | LvkonTZ410XS-LKM2504 |
| Maximum gross mass（kg） | 18000 |
| Curb weight（kg） | 10600/11000/11400 |
| Rated seats（person） | 78/18-39 or 97/18-39 |
| Wheel base（mm) | 5800 |
| Approach/departure angle(°) | 9/11 |
| Suspension system | Leaf spring，air spring |
| Tire | 275/70R22.5 |
| Energy storage system | LiFePO4 battery/CATL |
| Optional configuration | AC, electric defroster, interior electronic service devices |
| Maximum speed（km/h） | 69 |
6109EVEV14
Drive Devices
LvkonTZ410XS-LKM2504
Battery level
303.4/315kWh
| Specifications | |
|---|---|
| Dimensions（length x width x height）(mm) | 10500x2500x3070/3130/3230/3290 |
| Model of the driving motor | LvkonTZ410XS-LKM2504 |
| Maximum gross mass（kg） | 18000 |
| Curb weight（kg） | 10800/11200/11600 |
| Rated seats（person） | 78/18-39或97/18-39 |
| Wheel base（mm) | 5800 |
| Approach/departure angle(°) | 9/11 |
| Suspension system | Steel plate spring suspension, air suspension |
| Tire | 275/70R22.5 |
| Energy storage system | LiFePO4 battery/CATL |
| Optional configuration | AC, electric defroster, interior electronic service devices |
| Maximum speed（km/h） | 69 |
